OEM: Available
Standard: JIS, AISI, ASTM, GB, DIN, EN
Product Certification: ISO, CE, RoHS
Payment Terms: T/T, L/C, PayPal, Western Union
|
Specifications |
|
|
300 Series |
301, 302, 303, 304, 304L, 309, 309S, 310, 310S, 316, 316L, 316Ti, 317L, 321, 347 |
|
200 Series |
201, 202, 202Cu, 204 |
|
400 Series |
409, 409L, 410, 420, 430, 431, 440 |
|
Others |
2205, 2507, 2906, 330, 660, 630, 631, 17-4ph, 17-7 ph, 904L, ect |
|
Outer Diameter |
6mm-1400mm |
|
Wall Thickness |
0.89mm -60mm |
|
Length |
1~12 meters or customized |
|
Grade |
|
Chemical Component % |
||||||||||
|
|
C |
Cr |
Ni |
Mn |
P |
S |
Mo |
Si |
Cu |
N |
Other |
|
|
304 |
0Cr18Ni9 |
≤0.07 |
17.00-19.00 |
8.00-10.00 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
- |
- |
|
304L |
00Cr19Ni10 |
≤0.030 |
18.00-20.00 |
8.00-10.00 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
- |
- |
|
304H |
* |
0.040-0.1 |
18.00-20.00 |
8.00-10.00 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
- |
- |
|
304N1 |
0Cr19Ni9N |
≤0.08 |
18.00-20.00 |
7.00-10.50 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
0.10-0.25 |
- |
|
304N2 |
0Cr18Ni10NbN |
≤0.08 |
18.00-20.00 |
7.50-10.50 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
0.15-0.30 |
Nb≤0.15 |
|
304LN |
00Cr18Ni10N |
≤0.030 |
17.00-19.00 |
8.50-11.50 |
≤2.00 |
≤0.035 |
≤0.030 |
- |
≤1.00 |
- |
0.12-0.22 |
- |
304H Stainless Steel Tube has improved machinability characteristics. 304H also has excellent welding and deep drawing characteristics. 304H Stainless Steel Tube is most commonly used in petroleum refineries, Boilers, Heat exchangers, Condensers, Pipelines, Cooling towers, Steam exhausts, Electric generation plants, On occasion will be found in fertilizer and chemical plants.
1. Standard Exporting package.
2. Original package or neutral package.
3. According to clients ' needs.
4. Shipped in10-35 days after payment.
Price
Q: How can I get the 304 Stainless Steel Tube, 304L Stainless Steel Tube, 304H Stainless Steel Tube price?
A: You can contact us through sending inquiry, calling, or get details price list by E-mail.
Delivery
Q: How long is 304 Stainless Steel Tube, 304L Stainless Steel Tube, 304H Stainless Steel Tube delivery time?
A: It depends on quantity. Usually, 10-35 working days.
Sample
Q: Can I get 304 Stainless Steel Tube, 304L Stainless Steel Tube, 304H Stainless Steel Tube sample to check the quality?
A: Of course. We can supply sample, and free for some small value products.
OEM
Q: Do you provide OEM service?
A: Yes, we do. Customized design is available.
Payment
Q: What is your payment term?
A: L/C, T/T, PayPal, Western Union, etc.
Certificate
Q: What certificate do your products have?
A: CE, ISO9001, RoHS, SGS, etc.
304L Stainless Steel Tube is the most versatile and widely used stainless steels. 304L Stainless Steel Tube exhibits excellent corrosion resistance to a wide range of corrosive environments. 304L Stainless Steel Tube commercial tubing grades exhibits good machinability and have excellent weld-ability characteristics with or without the addition of filler metals.
304 Stainless Steel Tube sizes bear little resemblance to the actual dimensions. 304 Stainless Steel Tube is shown as Nominal Bore (NB) in inches (this is not the actual dimension) and a schedule which relates to the wall thickness. 304 Stainless Steel Tube is the standard commercial grade for stainless steel pipe, 304 Stainless Steel Tube provides good corrosion resistance and good machinability. Elbow fittings are available for the majority of our pipes.
