Nimonic 80A alloy is a nickel-chromium alloy that is strengthened by the additions of titanium and aluminum. It has high tensile and creep-rupture properties at temperatures up to 815°C (1500°F).
Chemical Composition | ||||||||||
Grade | % | Ni | Cr | Fe | C | Mn | Si | |||
Nimonic 80A | Min | Rest | 18 |
|
|
|
| |||
Max | 21 | 3 | 0.1 | 1 | 1 | |||||
| Co | S | B | Ti | P | Cu | Al | |||
|
|
|
| 1.8 |
|
| 1 | |||
| 2 | 0.015 | 0.008 | 2.7 | 0.02 | 0.2 | 1.8 | |||
Physical Performance | ||||||||||
Density | 8.19 g/cm3 | |||||||||
Smelt Point | 1320-1365 | |||||||||
Grade | T*S | Y*S | El | Hardness | ||||||
Rm N/mm2 | RP0.2N/mm2 | A5 % | HB | |||||||
Nimonic 80A | 920 | 550 | 25 | / | ||||||
Nimonic 80A alloy is currently used for gas-turbine components such as blades, rings and discs; for bolts, nuclear boiler tube supports, die-casting inserts and cores, and for automobile exhaust valves.
1. Standard Exporting package.
2. Original package or neutral package.
3. According to clients ' needs.
4. Shipped in10-35 days after payment.
Price
Q: How can I get the price?
A: You can contact us through sending inquiry, calling, or get details price list by E-mail.
Delivery
Q: How long is the delivery time?
A: It depends on quantity. Usually, 10-35 working days.
Sample
Q: Can I get sample to check the quality?
A: Of course. We can supply sample, and free for some small value products.
OEM
Q: Do you provide OEM service?
A: Yes, we do. Customized design is available.
Payment
Q: What is your payment term?
A: L/C, T/T, PayPal, Western Union, etc.
Certificate
Q: What certificate do your products have?
A: CE, ISO9001, RoHS, SGS, etc.
